High Speed Facial Tissue Machine 4800 Sheets / Min For Cube Box Facial Tissue
Description
High Capacity Facial Tissue Machine For Cube Box Facial Tissue is designed to produce facial tissue with high speed, nice folding and easy operation. It will count the
paper automatically and output in order. And adopting screw turning knife to cut and vacuum absorption
to fold and frequency invertor to adjust speed to roll and fix different tension of raw paper, adopts
advanced PLC computer program control, with human-machine interface data input. It has wide range of production width for selection.
Specification
| Finished Paper Size | 200×200±2mm (Other size can be specified) |
| Diameter of jumbo rolls | ≤Φ1200 (Other size can be specified) |
| Paper core inner diameter of jumbo rolls | 76.2mm (Other size can be specified) |
| Speed | 60-80M/Min |
| Controller | Electric-Magnetic adjust |
| Embossing equipments | Steel to Steel |
| Enbossing condition | Wool cloth roller, wool roller, rubber roller and steel roller |
| Side rolling embossment | Steel to Steel , self-contained controller |
| Slitting system | Pneumatic mode point-cutting |
| vacuum system | 7.5KW |
| Pneumatic system Pressure | > 4kg/cm2 (provided by customers) |
Main Specification
-
Speed: 4800sheets/min
-
Folding Type: Interfold
-
Edge Embossing
-
Frequency Converter Delta
-
Motor: Siemens
-
Pneumatic Parts AIRTAC
-
20mm thickness wall board plate for back stand
-
40mm thickness wall board plate for embossing unit
-
30mm thickness wall board plate for cylinder folding parts
-
Photoelectrical switch (magic eye) Omron
Electrical Parts and other Parts brand
| NO | Name | Brand | Original Place |
| 1 | Motor | Siemens | China |
| 2 | Pneumatic Parts | Omron | Germany |
| 3 | Vacuum Pump | Longtech | Taiwai |
| 3 | Frequency converter | Delta | Taiwai |
Box-drawing facial tissue machine is to cut a good plate of paper folded into the process "V" type of paper
processing equipment, machinery and mechanical hand using vacuum assisted folding principle.
1. Automatic counting sub-bit row of output;
2. Screw shear knives, vacuum folding;
3. Variable speed unwinding, can be adapted to base level of tension;
4. Controlled by PLC computer programming, pneumatic, on paper, easy to operate;
5. Frequency conversion motor to save energy;
6. Product width can be adjusted to facilitate marketing;
7. Supporting paper, paper pattern edge rolling device, the pattern is clear, flexible and market demand. (Pattern selected by the guests)
Product Description
High Quality Facial Tissue Machine Paper Product Making Machinery
Features:
Facial tissue making machine working flow:The jumbo rolls which have been slit into the desired width are cut by the slitting cylinders,and then interfolded into interoverlapped rectangular facial tissue sheets.
This machine adopts independent servo motor drive,and automatic paper tension control automatic marking functings.It featurse of high speed,nice folding and easy operation.
1.Can order steel to rubber embossing rolls,pneumatically separated.
2.Wallboard rack and Machine running stability and extremely good and fast.
3.Pneumatic jumbo roll loading,pneumatic paper driving,stepless speed additionstment,and web tension control.
4.Equipped with roots type vacuum pump for stable running of the machine.
5.Make various products width as requirement.
6.Equipped with edge embossing unit to keep the plise together.
7.The machine will stop when the paper broken.It avoid waste caused by no paper or paper broken.
8.The web can be threaded on the machine by the two jog buttons,It's more safer and easier to thread the web.
1. Specification of Facial Tissue Folding Machine:
| Machine Model | SYM-190/6L (Other size to be specified) |
| Finished Products Unfolded Size | 95x(120-210)x2mm |
| Folding Products Size | 190x(120-210)x2mm |
| Raw Material Width | 1260mm |
| Raw Material Diameter | 1200mm |
| Raw Material Core Diameter | 76.2mm |
| Output Capacity (8 hours) | 2000-3000kg |
| Embossing Unit | Steel to rubber |
| Edge Embossing | Steel to steel edge embossing, independent pneumatic regulation |
| Slitting Unit | Pneumatic slitting |
| Main Servo Moter Power | 5.5kw |
| Unwind Frequency Motor Power | 1.5kw (2 units) |
| Vacuum System | 18.5 kw Vacuum pump (Taiwan Roots blower) |
| Pneumatic System | 3HP air compressor,Min. pressure 5kg/cm2PA (Provider by user themselves) |
| Driving System | Timing belt |
| Dimension | 5870x2800x2207mm |
| Weight | About 5 tons |
2. Specification of Single Channel Log Saw Cutting Machine:
| Designation | Parameter values |
| The length of the none cut off facial tissue | minimum 500mm |
| The Height of tissue | 30~130mm |
| Machine Speed | 20~150cut/min |
| Operating speed | 20~120cut/min |
| Round blade outer diamete | Φ610mm |
| Paper cutting circular knife top speed | 980R/min |
| Finished products specification | 70~300mm |
| Paper width | 70~110mm |
| Cutting Length | 70~300mm |
| Left-over Length | 20~65mm |
| Power | 11KW |
| Power supply | 380V 50Hz |
| Air source | 0.5~0.8MPa |
| Machine Size | 4600*1700*2500mm |
| Weight of machine | 2300~2600kg |
| Brake | Parameter setting (auto/manual) |
| Stepping sharpening knife | Parameter setting (auto) |
| Pneumatic sharpening knife | Parameter setting (auto/manual) |
| Blow air | without |
| The total pressure switch | Value (not) |
| Human-computer interface | DELTA |
| Frequency changer | |
| Servo Drive | DELTA |
3. Specification of Facial Tissue Packing Machine:
1. Adopting packing way by wrapping, folding and sealing with compact structure, it makes the package look beautiful and the seal tightened.
2. Controlled by stepless speed regulation, touch screen and PLC, the display on the human-machine interface makes maintenance more simply.
3. Applied with auto-arranging feeding conveyor, it is convenient to connect the conveyor with automatic production line, saving the labor cost to the maximum.
4. It saves much packing material by means of photocell checking, servo tracking, and auto-stop of film feeding without product.
5. High automation, high profession, high efficiency and less trouble.
6. With wide packing size range, various packing sizes can be quickly interchanged.
| Tissue sizes: | L: 150-400mm W: 150-200mm H: 35-150mm |
| Packing speed: | 40-70 bags/min |
| Air supply: | 0.5-0.8MPa |
| Machine weight: | 3300kg |
| Outer dimensions (LxWxH): | 5885x3560x1925(mm) |
| Heating power: | 3.6kw |
| Motor power: | 3.6kw |
| Packing size: | ≤230x190x100(mm) |
| Working noise: | ≤78dB |
| Packing film: | CPP |
| Power supply type: | 380V, 50Hz |
4.Specifications of Semi Automatic Two Outlets Multi Bags Packing Machine:
| Packing Size | ≤500x300x110mm (LxWxH) |
| ≥220x120x90mm (LxWxH) |
| Packing Speed | 10-20 bag/min |
| Gas Pressure | 0.5mpa-0.8mpa |
| Voltage & Frequency | 380V,50Hz,3Phase |
| Total Power | 0.8kw |
| Weight | 1000kg |
| Overall Dimension | 4900x1650x1280mm |
| Tissue paper bag (one row/two rows) | Tissue paper bag (one row/two rows) |
