Industrial Paper Roll Slitting And Rewinding Machine With PLC
Control
Description
Siemens PLC Industrial Paper Toilet Roll Slitting and Rewinding
Machine is used to slit and rewind the bathroom tissue, non-woven
materials. The single ply paper can be slit and rewinded into two,
three or four ply paper with various widths, for the production of
napkins, hankies, facials or sanitary napkins.
Specification
| Width of raw paper | 1800mm | 2200mm |
| Diameter of finished products | Φ90~300mm(adjustable) |
| Diameter of raw material | Φ1600mm(can be specified) |
| ID of raw material core | 76.2mm(can be specified) |
| Perforating pitch | 90-160mm |
| Capacity | 150-180m/min |
| Rewinding unit | Air shaft |
| Unwinding stand | 1-3 layers(customizable) |
| Pneumatic system | 3HP air compressor, min. Air pressure is 5kg/cm2 Pa(provided by
customer) |
| Power | 4.5KW |
| Overall dimension | 5800mm*2800mm*1750mm |
| Weight | According to different models |
Functions and Features
1 . Synchronous belt transmission, make it stable-running and less
noise even though at high speed operation.
2 . Adopt the widen belt on back-stand to increase the friction
when feeding paper.
3 . Equipped with newly fasten unit, making it is convenient to
adjust the raw material.
4 . With the function of pneumatic paper loading, edge vacuum
suction.
5 . Automatic finished roll discharging, Solve the deformation
caused by falls paper phenomenon, save the labor force. (Optional)
6 . Easy operation, the finished products have good winding
profiles and clean cutter.
Optional Equipment:
1. Two embossing units can be equipped with 3 laying paper stand.
2. Electric unit adopts famous brand of China, called “Zheng da”
electric unit. This machine also equip with PLC, it has reasonable
structure and easy operation.
3. Axletree adopts famous brand of China, called Ha er bin
axletree.
The name of spare part of the machine:
1. Use processing, anti-pressure and capable of damage transition
of steel axle.
2. Electric unit adopts famous brand of China, called “Zheng da”
electric unit. This machine also equip with PLC, it has reasonable
structure and easy operation.
3. Axletree adopts famous brand of China, called Ha er bin
axletree.
Electrical Parts and other Parts brand
| NO | Name | Brand | Original Place |
| 1 | Frequency Panel | Siemens | Germany |
| 2 | Motor | Siemens | Germany |
| 3 | Pneumatic Parts | Schneider | Germany |
| 4 | Knife bearing | NSK | Japan |
| 5 | Steel | SKD | Japan |
| 6 | Touch Screen | Delta | Taiwan |
Factory Sale Low Price Tissue Paper Production Line Toilet Paper
Making Machine For Sale
Features:
Automatic High Speed Toilet Paper/ Maxi Roll Rewinding Machine is
for toilet paper roll/maxi roll processing.
Machine have core feeding unit, can do both with and without core.
Raw material from jumbo roll after full embossing or edge
embossing, then perforation, end cutting and spray the tail glue
become a log. Then it can working with cutting machine and packing
machine to become the finished products. The machine is controlled
by PLC, people operate it through touch screen, the whole process
is automatic, easy to operate, lower the man cost. And Our machine
can special-made according to clients' requirements.
Model | 1092B | 1575B | 1760B | 2150B | 2200B | 2500B | 2800B |
Jumbo Roll Max. width | 1350mm | 1750mm | 1880mm | 2000mm | 2150mm | 2400mm | 2750mm |
Max. Jumbo Roll diameter
| 2-3 stands (pls specify when order)
Paper gram weight 13-16 g/m2 |
Jumbo Roll Standings
| Standardφ3"(76.2mm) (Other sizes specified)
|
Data setting
| HMI |
Programming controller
| PLC, touch screen
|
Operate Speed
| 0-230m/min 15000-25000 rolls/8hours |
Finished Log Outer dia. | φ90-140mm |
Finished Log Inner dia. | φ38-76mm |
Perforation Distance | 100-150mm |
Mechanical driving
| Driving by Stepless gear box
|
Air -system
| 3HP air compressor, min. pressure 5kg/cm2pa ( provide by user)
|
Main driving
| Frequency conversion speed regulation 7.5-15KW 380V,50HZ
|
Embossing unit
| Steel to rubber
|
Dimensions | 6x3x1.7 (length x width x height);(m)
|
Weight | 3T-4T(depends on the Model you have )
|
Options: | |
Embossment Roller | Plane, Single Set, Double Sets Can be ordered |
Color Printing Unit
| 1-2 Colors can be order
|
Lamination Unit
| Can be Ordered
|
Edge-Embossing Line
| Steel to Steel Operate by Pneumatic
|
Deco Color Lamination Parts:
